M13Z-145

M13Z-145

Large Woven Wire Mesh Pattern

Transparency Model Specification Sheet Contact Us

Large scale, three wire, rigid cable patterned after traditional european designs. Long aspect ratio clearly differentiates the vertical pattern from the horizontal. Strong and available in many different finishes.

Pattern Details

Percent Open:64.5%

Overall Thickness:0.402

Crimp Style: PS3PZ

Aspect Ratio:7.01:1

Opening Limitation:0.430

Weight:1.85 lbs./sq. ft.

Available Raw Materials: Click here for more information on Raw Materials


Available Secondary Finishes

PlatedPowder CoatUS10AUS10B

Click here for more information on Secondary Finishes
photo-icon Stainless Steel (A) / Brass (B) photo-icon Stainless Steel (A) / Bronze (B) photo-icon Stainless Steel (A) / Copper (B) photo-iconStainless Steel photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconBrass photo-iconGeneral photo-iconBronze photo-iconGeneral photo-iconCopper photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconPlated - Antique Brass photo-iconGeneral photo-iconPlated - Antique Copper photo-iconGeneral photo-iconPlated - Antique Nickel photo-iconGeneral photo-iconPlated - Black Copper photo-iconGeneral photo-iconPlated - Bright Copper photo-iconGeneral photo-iconPlated - Bright Brass photo-iconGeneral photo-iconPlated - Dark Oxide photo-iconGeneral photo-iconPlated - Satin Brass photo-iconGeneral photo-iconPlated - Bright Chrome photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral photo-iconGeneral
stainless testing brass testing bronze testing copper testing plated-copper testing plated-brass testing plated-dark-oxide testing plated-black-copper testing plated-satin-brass testing plated-bright-chrome testing plated-nickle testing plated-bright-copper testing plated-bright-brass testing ss-brass testing ss-bronze testing ss-copper testing stainless plain-steel weathering-steel pre-galv galfan brass bronze copper aluminum ss-brass ss-bronze ss-copper brass-ss ss-brass-ss ss-brass-ss-brass bronze-ss ss-bronze-ss ss-bronze-ss-bronze copper-ss ss-copper-ss ss-copper-ss-copper ss-ss-brass ss-ss-bronze ss-ss-copper ss-brass-brass ss-bronze-bronze ss-copper-copper brass-ss-ss bronze-ss-ss copper-ss-ss ss-b-brass-brass ss-b-bronze-bronze ss-b-copper-copper pvd-champagne-gold pvd-gunmetal pvd-multi pvd-rose-gold pvd-royal-gold pvd-chocolate-gold plated-brass plated-copper plated-nickle plated-black-copper plated-bright-copper plated-bright-brass plated-dark-oxide plated-satin-brass plated-bright-chrome powder-black powder-black-oil powder-black-raven powder-multi us10a us10b

Stainless Steel


a small ruler that is set in inches
All Finishes Raw Materials Secondary Finishes

❮
❯


Important Note Regarding Color
Please note that due to the limitations and relative inconsistencies of digital displays, the original and artificially colorized photography above is intended to only be a representation of the raw materials Banker Wire uses and is not a substitution for physical samples. Banker Wire manufactures all wire mesh in a bare mill finished condition. Please always confirm size, color, and finishes of wire mesh patterns with physical samples.



M13Z-145

banker wire logo for our print page

print ready image for M13Z-145 img b height marker img a height marker

Pattern Details

Percent Open:64.5%

Aspect Ratio:7.01:1

Weight:1.85 lbs./sq. ft.

Overall Thickness:0.402 in.

Crimp Style:PS3PZ

Opening Limitation:0.430 in.

What are your dimensions?

We manufacture every job to size. List the dimensions and any addition details of your job. special notes sections Please double check that your sizes and materials are within our Maximum Dimensions below.

"Maximum" Dimensions of available raw material configurations

Max. A
Max. B
Raw Material Configuration

240
96


Notes

*Weight based on the specific density of mild (plain) steel **Maximum sphere diameter which will pass through opening Product specifications are subject to change. Product image is shown at 100% unless stated otherwise. For accuracy, specification sheet must be printed with no scaling. Measurements and data are approximate and should be confirmed with a physical sample.
