Opaque Woven Wire Mesh Pattern

gallery image ruler image
Notes: Product photography not to scale. Please download the woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample. DS-076DS-76
Transparency Model Specification Sheet

The DS-76 opaque style weave displays three consecutive square wires before the heddle frames change. The angular shape of the square wire gives this wire mesh pattern definition unlike that of a round wire. Typically used for many different surfacing applications, the mesh precision and strength easily allows for the cutting of special shapes or complete cutouts of special shapes.

Pattern Details

Percent Open:0.0%

Overall Thickness:0.189

Crimp Style: PD3EZ

Aspect Ratio:1.88:1

Opening Limitation:0.000

Weight:3.10 lbs./sq. ft.


Available Raw Materials: Click here for more information on Raw Materials

Available Secondary Finishes
Click here for more information on Secondary Finishes
