DS-78

DS-78

Opaque Woven Wire Mesh Pattern

Specification Sheet Contact Us
The DS-78 architectural wire mesh has a complicated repeating pattern made simple with Banker Wire loom technology.  Square cross wires gives this pattern a slightly more contemporary look than that of the more traditional DS-81.

Pattern Details

Percent Open:0.0%

Overall Thickness:0.189

Crimp Style: D11EZ

Aspect Ratio: 1.95:1

Opening Limitation: 0.000

Weight: 3.10 lbs./sq. ft.

Available Raw Materials:
stainless material

Click here for more information on Raw Materials
photo-icon photo-icon photo-icon photo-icon photo-icon

Stainless Steel Finish Overview Stainless Steel Stainless Steel Angle View Stainless Steel Opposite Side
Ruler a small ruler that is set in inches


Stainless Steel


All Finishes Raw Materials Secondary Finishes

❮
products-materials-icons
❯


Important Note Regarding Color
Please note that due to the limitations and relative inconsistencies of digital displays, the original and artificially colorized photography above is intended to only be a representation of the raw materials Banker Wire uses and is not a substitution for physical samples. Banker Wire manufactures all wire mesh in a bare mill finished condition. Please always confirm size, color, and finishes of wire mesh patterns with physical samples.



A small hamburger icon, navigation for interior page vertical movement. Top of Page Pattern Details Related Projects Related Press Related Products
Chat Icon close icon contact us icon

How can we help?

General Inquiry Quote Request Sample Request

Give us a call!

+1 262-363-6120

We use cookies to improve your experience on our website. By closing this banner or interacting with our site, you acknowledge and agree to this.

DS-78

banker wire logo for our print page

print ready image for DS-78 img b height marker img a height marker

Pattern Details

Percent Open:0.0%

Aspect Ratio:1.95:1

Weight:3.10 lbs./sq. ft.

Overall Thickness:0.189

Crimp Style:D11EZ

Opening Limitation:0.000 in.

What are your dimensions?

We manufacture every job to size. List the dimensions and any addition details of your job. special notes sections Please double check that your sizes and materials are within our Maximum Dimensions below.

"Maximum" Dimensions of available raw material configurations

Max. A
Max. B
Raw Material Configuration

120
60
printable material icon


Notes

*Weight based on the specific density of mild (plain) steel **Maximum sphere diameter which will pass through opening Product specifications are subject to change. Product image is shown at 100% unless stated otherwise. For accuracy, specification sheet must be printed with no scaling. Measurements and data are approximate and should be confirmed with a physical sample.
