DS-67



DS-67

Opaque Woven Wire Mesh Pattern

gallery image ruler image
Notes: Product photography not to scale. Please download the woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample. DS-067 – Architectural Woven Wire MeshDS-67
Specification Sheet

DS-67 is an opaque woven wire mesh pattern that alternates three patterns of four .125" wide flat wire and then a single .375" wide strip.  Based on a Flat Top crimp style, each side of this mesh is unique.

Pattern Details

Percent Open:0.00%

Overall Thickness:0.189

Crimp Style:PDXEZ

Aspect Ratio:9.55:1

Opening Limitation:0.000

Weight:3.070 lbs./sq. ft.



Available Raw Materials: StainlessSteel_Icon2 Bronze_Icon2 Brass_Icon2 Click here for more information on Raw Materials

Available Secondary Finishes

PVDUS10AUS10B

Click here for more information on Secondary Finishes
