S-47



S-47

Large Woven Wire Mesh Pattern

gallery image ruler image
Notes: Product photography not to scale. Please download the woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample. S-047 – Architectural Woven Wire MeshS-47
Specification Sheet

A classic furniture mesh pattern that is slightly crushed can be used in either a square orientation or a diamond orientation.  Traditionally woven in bare steel and plated as shown in an antique brass finish, this pattern can be woven in a sorts of alloys.

Pattern Details

Percent Open:78.60%

Overall Thickness:0.160

Crimp Style:ELEL

Aspect Ratio:1.00:1

Opening Limitation:0.670

Weight:0.575 lbs./sq. ft.



Available Raw Materials: StainlessSteel_Icon2 PlainSteel_Icon2 Bronze_Icon2 Brass_Icon2 Copper_Icon2 Click here for more information on Raw Materials

Available Secondary Finishes

PVDPlatedPowder CoatUS10AUS10B

Click here for more information on Secondary Finishes



S-47 Photos
