WDZ-539

Ornamental Welded Wire Mesh

Specification Sheet Contact Us

The WDZ-539 is a rectangular ornamental welded wire mesh pattern with a 7.5:1 aspect ratio. Cross wires are spaced every 1 inch while a trio of line wires are grouped every 7.50 inches. There are 6 groups of 3 line wires within a standard 48”x96” sheet. There are 8 groups of 3 line wires within a standard 60”x96” sheet. Do you have a question or would you like to see a sample of our Ornamental Welded Wire Mesh? Our knowledgeable sales staff can assist you with sample requests, quotes, and any additional questions you may have regarding this Ornamental welded wire mesh pattern. Call us toll-free at 1-800-523-6772, or visit our Request for Quote page.

Pattern Details

Percent Open:74.6%

Overall Thickness:0.384

Crimp Style: WDWDZ

Aspect Ratio: 7.50:1

Opening Limitation: 0.808

Weight: 1.74 lbs./sq. ft.

Available Raw Materials:

Click here for more information on Raw Materials Available Secondary Finishes:

Plated Powder Coat

Click here for more information on Secondary Finishes

What can Banker Wire welded wire mesh do for you?Learn More

Stainless Steel

All Finishes Raw Materials Secondary Finishes

❮

❯

Important Note Regarding Color
Please note that due to the limitations and relative inconsistencies of digital displays, the original and artificially colorized photography above is intended to only be a representation of the raw materials Banker Wire uses and is not a substitution for physical samples. Banker Wire manufactures all wire mesh in a bare mill finished condition. Please always confirm size, color, and finishes of wire mesh patterns with physical samples.

A small hamburger icon, navigation for interior page vertical movement.

Top of Page Pattern Details

Custom wire mesh and additional specifications available.

Inquire now or call us at 262-363-6120

WDZ-539

Pattern Details

Percent Open:74.6%

Aspect Ratio:7.50:1

Weight:1.74 lbs./sq. ft.

Overall Thickness:0.384

Crimp Style:WDWDZ

Opening Limitation:0.808 in.

What are your dimensions?

We manufacture every job to size. List the dimensions and any addition details of your job. special notes sections

Please double check that your sizes and materials are within our Maximum Dimensions below.

"Maximum" Dimensions of available raw material configurations

Max. A

Max. B

Raw Material Configuration

240

Notes

*Weight based on the specific density of mild (plain) steel **Maximum sphere diameter which will pass through opening Product specifications are subject to change. Product image is shown at 100% unless stated otherwise. For accuracy, specification sheet must be printed with no scaling. Measurements and data are approximate and should be confirmed with a physical sample.
