M22-46



M22-46

Mid-Fill Woven Wire Mesh Pattern

gallery image ruler image
Notes: Product photography not to scale. Please download the woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample. M22-046 – Architectural Woven Wire MeshM22-46
Specification Sheet

Mid-scale twin wire intercrimp weave is slightly scaled up from the M22-28 pattern.  The increase in wire diameter stiffens up the mesh pattern when rigidity matters.

Pattern Details

Percent Open:61.00%

Overall Thickness:0.160

Crimp Style:2P2P

Aspect Ratio:1.00:1

Opening Limitation:0.540

Weight:1.020 lbs./sq. ft.



Available Raw Materials: StainlessSteel_Icon2 PlainSteel_Icon2 PreGalv_Icon2 Aluminum_Icon2 Bronze_Icon2 Brass_Icon2 Copper_Icon2 Click here for more information on Raw Materials

Available Secondary Finishes

PVDPlatedPowder CoatUS10AUS10B

Click here for more information on Secondary Finishes



Projects Related To M22-46

Club Level at M&T Bank StadiumView Details
