L-48



L-48

Mid-Fill Woven Wire Mesh Pattern

gallery image ruler image
Notes: Product photography not to scale. Please download the woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample. L-048 – Industrial Woven Wire Mesh Lock CrimpL-48
Specification Sheet

The Banker Wire L-48 is a 3/4" OPG .162 Lockcrimp woven wire mesh specification. This square weave can be woven in a variety of alloys including: Stainless Steel, Plain Steel, Weathering Steel, Pre-Galvanized Steel, Galfan, Brass, Bronze, Copper, Aluminum.

Pattern Details

Percent Open:67.6%

Overall Thickness:0.324

Crimp Style: LCLC

Aspect Ratio:1.00:1

Opening Limitation:0.750

Weight:1.87 lbs./sq. ft.



Available Raw Materials: Click here for more information on Raw Materials


Available Secondary Finishes

PlatedPowder CoatUS10AUS10B


Click here for more information on Secondary Finishes


  • Facebook icon
  • Houzz icon
  • Archello icon
  • Youtube Icon
  • Linkedin icon
  • Pinterest icon
  • Twitter icon
  • instagram icon icon

Banker Wire Manufactures American-made Products, logo for banker wire icon
©2022, C I Banker Wire & Iron Works. All rights reserved.

Privacy Policy Terms and Conditions

Banker Wire is your quality driven manufacturing partner for woven and welded mesh.
Inquire now or call 1-800-523-6772.



We use cookies to improve your experience on our website. By closing this banner or interacting with our site, you acknowledge and agree to this.

L-48

banker wire logo for our print page

print ready image for L-48 img b height marker img a height marker

Pattern Details

Percent Open:67.6%

Aspect Ratio:1.00:1

Weight:1.87 lbs./sq. ft.

Overall Thickness:0.324 in.

Crimp Style:LCLC

Opening Limitation:0.750 in.

What are your dimensions?

We manufacture every job to size. List the dimensions and any addition details of your job. special notes sections Please double check that your sizes and materials are within our Maximum Dimensions below.

"Maximum" Dimensions of available raw material configurations

Max. A
Max. B
Raw Material Configuration

1200
96


Notes

*Weight based on the specific density of mild (plain) steel **Maximum sphere diameter which will pass through opening Product specifications are subject to change. Product image is shown at 100% unless stated otherwise. For accuracy, specification sheet must be printed with no scaling. Measurements and data are approximate and should be confirmed with a physical sample.
