DS-7



DS-7

Opaque Woven Wire Mesh Pattern

gallery image ruler image
Notes: Product photography not to scale. Please download the woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample. DS-007 – Architectural Woven Wire MeshDS-7
Specification Sheet

DS-7 opaque woven wire mesh pattern that has a watchband appearance.  Alternating flat wire widths that are crimped in a smooth plain crimp style creates this elegant surfacing material.

Pattern Details

Percent Open:0.00%

Overall Thickness:0.220

Crimp Style:PD2PZ

Aspect Ratio:3.00:1

Opening Limitation:0.000

Weight:4.080 lbs./sq. ft.



Available Raw Materials: StainlessSteel_Icon2 Bronze_Icon2 Brass_Icon2 Stainless-Bronze_Icon2 Stainless-Brass_Icon2 Click here for more information on Raw Materials

Available Secondary Finishes

PVDUS10AUS10B

Click here for more information on Secondary Finishes
