DF-1



DF-1

Opaque Woven Wire Mesh Pattern

gallery image ruler image
Notes: Product photography not to scale. Please download the woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample. DF-001 – Architectural Woven Wire MeshDF-1
Transparency Model Specification Sheet

The DF-1 woven wire mesh pattern is a classic dutch style weave that uses bright embossing technology applied to traditional flat top cross wires producing a beautifully faceted cladding product. Because the facets only deviate slightly from the plane of the fabric, very interesting reflective patterns develop at a near-perpendicular viewing perspective. This is an asymmetric fabric.

The DF-1 mesh pattern is an opaque weave that is typically affixed to a rigid backer panel for vertical and horizontal surfacing. The DF-1’s unique strength and beauty makes this mesh a good choice for elevators, lobbies, airports, and retail environments.

Pattern Details

Percent Open:0.00%

Overall Thickness:0.206

Crimp Style:PDFTZ

Aspect Ratio:10.56:1

Opening Limitation:0.000

Weight:2.362 lbs./sq. ft.



Available Raw Materials: StainlessSteel_Icon2 Bronze_Icon2 Brass_Icon2 Click here for more information on Raw Materials

Available Secondary Finishes

Click here for more information on Secondary Finishes



DF-1 Photos



Notes:

Product photography not to scale. Please download the woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample. All weight measurements are based on the specific density of mild (plain) steel. For conversion information, please refer to the Weights and Conversions section of our Woven Wire Basics Page or, contact us. It should be noted that architectural fabrics produced from very smooth, diamond drawn wires will, at times, exhibit striations of varying degrees of light and dark. These are not defects, but rather, part of the natural beauty of the material. Maximum dimensions may change based on alloy selection. Please contact us for additional details.
