DELTA 24RG

Delta 24RG Flexible Mesh in Blue Powder Coat for architectural applicationsAdditional Images
Delta 24RG Flexible Mesh in Blue Powder Coat for architectural applicationsDelta 24RG Flexible Mesh used as space divider at Buffalo Wing FactoryDelta 24RG Flexible Mesh for architectural applicationsBanker Wire Flexible Mesh finish options

DELTA 24RG

Flexible Mid-Fill Spiral Mesh Pattern

Specification SheetContact Us
A simple flexible spiral mesh configuration using round wire.  This Delta 24RG wire mesh pattern is a basic spiral weave construction that can be scaled in size.  Combining common spiral pitches creates interesting density changes throughout a continuous length.  The Delta 24RG is available in T316 stainless steel and aluminum.  Adding color through a  powder coating finish is also available for this pattern.  Multiple flexible mesh mounting systems are available to help bring your vision to life.  Or, contact us and we can discuss the options that are right for your project.

Pattern Details

Percent Open:51.0%

Overall Thickness:0.273

Crimp Style: BTPLZ

Aspect Ratio: 1.91:1

Opening Limitation: .2064

Weight: 1.49 lbs./sq. ft.

Available Raw Materials:
stainless materialaluminum material

Click here for more information on Raw MaterialsAvailable Secondary Finishes:
Powder CoatAnodized

Click here for more information on Secondary Finishes
photo-iconphoto-iconphoto-iconphoto-icon

Stainless SteelPowder Coat - Various Finish OverviewPowder Coat - Various
Ruler a small ruler that is set in inches


Stainless Steel


All Finishes Raw Materials Secondary Finishes

❮
products-materials-iconssecondary-finishes
❯


Important Note Regarding Color
Please note that due to the limitations and relative inconsistencies of digital displays, the original and artificially colorized photography above is intended to only be a representation of the raw materials Banker Wire uses and is not a substitution for physical samples. Banker Wire manufactures all wire mesh in a bare mill finished condition. Please always confirm size, color, and finishes of wire mesh patterns with physical samples.




Projects Related To DELTA 24RG

Buffalo Wing FactoryView Details

Architectural Systems Related To DELTA 24RG

Round ThreadView DetailsLoopView Details

Additional Images

Delta 24RG Flexible Mesh used as space divider at Buffalo Wing FactoryDelta 24RG Flexible Mesh for architectural applicationsBanker Wire Flexible Mesh finish options
A small hamburger icon, navigation for interior page vertical movement. Top of Page Pattern Details Related Projects Related Press Related Products

DELTA 24RG

banker wire logo for our print page

print ready image for DELTA 24RG img b height marker img a height marker

Pattern Details

Percent Open:51.0%

Aspect Ratio:1.91:1

Weight:1.49 lbs./sq. ft.

Overall Thickness:0.273

Crimp Style:BTPLZ

Opening Limitation:.2064 in.

What are your dimensions?

We manufacture every job to size. List the dimensions and any addition details of your job. special notes sections Please double check that your sizes and materials are within our Maximum Dimensions below.

"Maximum" Dimensions of available raw material configurations

Max. A
Max. B
Raw Material Configuration

1200
216
printable material iconprintable material icon


Notes

*Weight based on the specific density of mild (plain) steel **Maximum sphere diameter which will pass through opening Product specifications are subject to change. Product image is shown at 100% unless stated otherwise. For accuracy, specification sheet must be printed with no scaling. Measurements and data are approximate and should be confirmed with a physical sample.
