DELTA 12R

Flexible Mid-Fill Spiral Mesh Pattern

A simple flexible spiral mesh configuration using round wire.  This Delta 12R wire mesh pattern is a basic spiral weave construction that can be scaled in size.  Combining common spiral pitches creates interesting density changes throughout a continuous length.  The Delta 12R is available in T316 stainless steel, copper and aluminum.  Adding color through a  powder coating finish is also available for this pattern.  Multiple flexible mesh mounting systems are available to help bring your vision to life.  Or, contact us and we can discuss the options that are right for your project.

Pattern Details

Percent Open:74.0%

Overall Thickness:0.50

Crimp Style: BTPLZ

Aspect Ratio: 1.09:1

Opening Limitation: .485

Weight: 1.22 lbs./sq. ft.

Available Raw Materials:
stainless materialcopper materialaluminum material

Click here for more information on Raw MaterialsCopper, Brass and Bronze are Living Finishes. Learn moreliving finishAvailable Secondary Finishes:
Powder CoatAnodized

Click here for more information on Secondary Finishes
