M13Z-345

right arrow
M13Z-345 Angle in Stainless Woven Wire Mesh
M13Z-345 Angle in Stainless Woven Wire Mesh
a arrow
 M13Z-345 in Stainless Woven Wire Mesh
 M13Z-345 in Bronze Woven Wire Mesh
 M13Z-345 in Bronze Woven Wire Mesh

Pattern Details

Percent Open:
59.8%
Overall Thickness:
0.360
Aspect Ratio:
8.42
Crimp Style:
TSPLZ
Weight:
1.62
Opening Limitation:
0.250
Max A:
240inches
Max B:
96inches

Available Raw Materials:

  • 00 - Stainless Steel Wire Mesh
  • 01 - Plain Steel Wire Mesh
  • 02 - Weathering Steel
  • 03 - Pre-Galvanized Wire Mesh
  • 04 - Galfan® Wire Mesh
  • 05 - Aluminum Wire Mesh
  • 06 - Bronze Wire Mesh
  • 07 - Brass Wire Mesh
  • 08 - Copper Wire Mesh

Available Secondary Finishes

Banker Wire offers a wide variety of secondary finishes through our outside vendors that can further enhance the aesthetic of any project. For more information, read about secondary finishes here.

PlatedPowder CoatUS10AUS10BPVD

Customization Options:

Customization of any wire mesh pattern is easy.  Banker Wire’s 100+ years of manufacturing experience makes it possible to create the wire mesh you envision right for your project.  We are likely to already have the tooling to produce what you are looking for and if not, we can design new tooling to make it within a few days.

lightbult icon

Customization of any wire mesh pattern is easy. Banker Wire's 100+ years of manufacturing experience makes it possible to create the wire mesh you envision right for your project. We are likely to already have the tooling to produce what you are looking for and if not, we can design new tooling to make it within a few days. Please contact us for more information.

800-523-6772
+44 (0) 1795 228 583
Notes

*Weight based on the specific density of mild (plain) steel **Maximum sphere diameter which will pass through opening Product specifications are subject to change. Product image is shown at 100% unless stated otherwise. For accuracy, specification sheet must be printed with no scaling. Measurements and data are approximate and should be confirmed with a physical sample.

Wire Mesh Pattern: M13Z-345

This medium-duty, triple shute weave aesthetically accentuates a vertical or horizontal look; from a distance, the three wavy wires create a wide band perpendicular to the straight wires. Banker Wire can produce over 800 triple shute wire mesh patterns as they can be scaled in many different ways, making it ideal for railing infill panels, parking garages, and screen walls. Bring your next project to Banker Wire, the worldwide leader in wire mesh, and we’ll help you create something extraordinary.

Customization Options:

Customization of any wire mesh pattern is easy.  Banker Wire’s 100+ years of manufacturing experience makes it possible to create the wire mesh you envision right for your project.  We are likely to already have the tooling to produce what you are looking for and if not, we can design new tooling to make it within a few days.

800-523-6772
+44 (0) 1795 228 583

Notes

Product photography not to scale. Please download the wire mesh and woven wire spec sheet for more accurate size representation. Always confirm measurements with a physical sample.

All weight measurements are based on the specific density of mild (plain) steel. For conversion information, please refer to the Weights and Conversions section of our Woven Wire Basics Page or, contact us.

It should be noted that architectural fabrics produced from very smooth, diamond drawn wires will, at times, exhibit striations of varying degrees of light and dark. These are not defects, but rather, part of the natural beauty of the material.

Maximum dimensions may change based on alloy selection. Please contact us for additional details.
